Diesel Injector Testing at Bingley MOT & Service Centre
The Merlin 4000 Mk2 test bench now allows for the on site diesel injector testing and, where required, the repairing or replacing of faulty diesel injectors. All work is carried out by our own team of fully trained motor engineers allowing you to leave your vehicle with us confident in the knowledge that it will be running smoothly when you collect it.
Makes and Models












WARNING SIGNS
If you have a diesel vehicle that is suffering from any of the following;
- Trouble starting the vehicle or uneven idling.
- Misfire.
- Smell of fuel.
- Dirty emissions.
- Increased fuel consumption and poor miles per gallon.
We can test a wide range of diesel injectors including those manufactured by the following leading companies. Our Merlin S4000 MK2 test bench allows us to thoroughly test the efficiency of your diesel injectors and to identify any faults which may exist.
Technical Details
MERLIN S4000 MK2
The Merlin S4000 MK 2 is a fully automatic common rail test bench designed and developed with the following functions:-
Tests BOSCH, DENSO, DELPHI, SIEMENS and CAT/Perkins common rail injectors.
Including:
Bosch CRi & CRIN
Bosch, Denso and Siemens Piezo
Delphi CR
Bosch CRIN 4.2
Bosch MTU
Cat/Perkins C4.4 – C6.6
Cat 9.3
Tests solenoid valve and Piezo injectors.
Automatically measures and displays delivered fuel quantity.

Diesel Injector Performance
Tests the seal performance of injectors and delivery under different working conditions as follows:-
Pre-injection
Idle
Mid-range
Max fuel
Equipped with original Bosch CP3 pump, rail, DRV and ZME.
Feeding pressure can be adjusted 0-6 bar.

Injector Testing
Test injection & return volume under VL, TL, LL, VE and VE2 status.
Atomization test to check for blocked nozzles.
Sealing test to check for leaks.
CODING
Capability to generate IMA C2i/C3i and QR Correction code for each individual injector.
